Asus P5GD1 User Manual

ASUS P5GD1ASUS P5GD1
ASUS P5GD1ASUS P5GD1
ASUS P5GD1
4-194-19
4-194-19
4-19
DRAM Frequency [Auto]DRAM Frequency [Auto]
DRAM Frequency [Auto]DRAM Frequency [Auto]
DRAM Frequency [Auto]
Allows you to set the DDR operating frequency. Configuration options:
[Auto] [333 MHz] [400 MHz] [600 MHz]
CPU Clock Spread Spectrum [Enabled]CPU Clock Spread Spectrum [Enabled]
CPU Clock Spread Spectrum [Enabled]CPU Clock Spread Spectrum [Enabled]
CPU Clock Spread Spectrum [Enabled]
Enables or disabled the CPU clock spread spectrum.
Configuration options: [Disabled] [Enabled]
PCIE Clock Spread Spectrum [Enabled]PCIE Clock Spread Spectrum [Enabled]
PCIE Clock Spread Spectrum [Enabled]PCIE Clock Spread Spectrum [Enabled]
PCIE Clock Spread Spectrum [Enabled]
Enables or disabled the PCI Express clock spread spectrum.
Configuration options: [Disabled] [Enabled]
Selecting a very high CPU frequency may cause the system to become
unstable! If this happens, revert to the default setting.
The following item appears only when the AI Overclocking item is set to
[Standard].
Memory Voltage [Auto]Memory Voltage [Auto]
Memory Voltage [Auto]Memory Voltage [Auto]
Memory Voltage [Auto]
Allows selection of the DDR SDRAM operating voltage. Set to Auto for safe
mode. Configuration options: [2.60V] [2.70V] [2.80V] [2.90V] [Auto]
Chipset Core Voltage [Auto]Chipset Core Voltage [Auto]
Chipset Core Voltage [Auto]Chipset Core Voltage [Auto]
Chipset Core Voltage [Auto]
Allows selection of the chipset core voltage.
Configuration options: [1.50V] [1.60V] [Auto]
CPU VCore Voltage [Auto]CPU VCore Voltage [Auto]
CPU VCore Voltage [Auto]CPU VCore Voltage [Auto]
CPU VCore Voltage [Auto]
Allows selection of the CPU VCore voltage.
Configuration options: [Auto] [1.7000V] [1.6875V] [1.6750] 1.6625V]
[1.6500V] [1.6375V] [1.6250V] [1.6125V] [1.6000V] [1.5875V]
[1.5750V] [1.5625V] [1.5500V] [1.5375V] [1.5250V] [1.5125V]
[1.5000V] [1.4875V] [1.4750V] [1.4625V] [1.4500V] [1.4375V]
[1.4250V] [1.4125V] [1.4000V] [1.3875V] [1.3750V]
CPU VCore Over Voltage Control [Disabled]CPU VCore Over Voltage Control [Disabled]
CPU VCore Over Voltage Control [Disabled]CPU VCore Over Voltage Control [Disabled]
CPU VCore Over Voltage Control [Disabled]
Enables or disables the CPU VCore over voltage control.
Configuration options: [Disabled] [Enabled]
FSB Termination Voltage [Auto]FSB Termination Voltage [Auto]
FSB Termination Voltage [Auto]FSB Termination Voltage [Auto]
FSB Termination Voltage [Auto]
Sets the Front Side Bus (FSB) termination voltage.
Configuration options: [1.20V] [1.40V] [Auto]

Asus P5GD1 Specifications

General

Form Factor	ATX
Chipset	Intel 915P
Socket	LGA 775
Front Side Bus	800/533 MHz
Memory Type	DDR
Memory Slots	4 x DIMM
Maximum Memory	4 GB
Expansion Slots	1 x PCIe x16, 3 x PCIe x1, 3 x PCI
USB Ports	8 x USB 2.0
LAN Speed	10/100/1000 Mbps
PS/2	2
CPU Type	Pentium 4 / Celeron D
Storage Interfaces	4 x SATA, 1 x ATA100
