Atlas Copco GA 110 VSD+ User Manual

Maximum cooling water outlet temperature (open systems) ˚C 50
Maximum cooling water outlet temperature (open systems) ˚F 122
Maximum cooling water outlet temperature (recirculating
systems)
˚C 60
Maximum cooling water outlet temperature (recirculating
systems)
˚F 140
Maximum cooling water inlet pressure bar(e) 10
Maximum cooling water inlet pressure psig 145
10.4 Settings of safety valve
The safety valve setting is 12 bar.
The safety valve setting is 174 psig.
10.5 Settings of overload relays, fuses and circuit breakers
Setting of fan protection for air-cooled compressors
Supply voltage (V) Q25/Q26 (A)
380 5.7
400 5.7
440 5.7
460 5.7
Setting of fan protection for water-cooled compressors
Supply voltage (V) Q16 (A)
380 1.1
400 1.1
440 1.1
460 1.1
Setting of dryer protection for air-cooled Full-Feature 50 Hz compressors
Instruction book
118 9829 3178 63
Model Working pressure (bar) Supply voltage (V) Q40 (A)
Q41,
Q42 (A)
GA 132 VSD+
8.5 400 12 1.9
GA 132 VSD+
10 400 10 1.3
GA 160 VSD+
8.5 400 12 1.9
GA 160 VSD+
10 400 12 1.9
GA 110 VSD+
8.5 400 12 1.9
GA 110 VSD+
10 400 12 1.9
