Atlas Copco PH 5 H User Manual

Repair instruction No. 170.6/96
PH 5 H, PH 5 F, PH 5 S, PHE 5 S
PAGE
2
Dismantling the
nosecone
3
Dismantling the
nosepiece
(PH 5 H, PH 5 F)
4
1 Hit the top housing (4) with a plastic
hammer to loosen the nosepiece (1) and
remove the nosepiece.
2 Remove the tolerance ring (2) and the
nosepiece seal (3).
12 3
1Hold the upper part of the machine in a
vice.
2 Lever out the nosecone retainer (1) with a
screwdriver and remove it.
3 Twist the nosecone (2) such that its four
reliefs match with the reliefs of the
nosepiece retainer (3) which is located
underneath.
4 Place the service tool 9170 3212 00 such
that its four lugs grasp the reliefs and
unscrew the nosecone clockwise.
5 Remove the O-ring (5) (only PH 5 H,
PH 5 F).
6 Remove the the front handle strap
assembly (4) and the nosepiece
retainer (3).
4
123 4
5
☛
The steps 4-7 describe the dismantling of machines with spline shaft reception (PH 5 H, PH 5 F).
For dismantling machines with SDS-max reception (PH 5 S), please proceed with step 8.
Note
Detaching the
front bearing
housing
(PH 5 H, PH 5 F)
12
1Hold the machine in a vice.
2 Unscrew and remove the front bearing
housing (2) with service tool 9170 3020 90
(left-handed thread!).
3 Remove the driver together with the barrel
(1) from the machine.
Separating the
driver from the
barrel
(PH 5 H, PH 5 F)
1
2
1 Fix the service tool no. 9170 3022 60 in a
vice.
2 Fix the driver (1) together with the barrel
(2) in the service tool and unscrew the
driver (1) (only PH 5 F) from the barrel (2)
with aid of an Allen key.
1
2
PH 5 H
PH 5 F
PH 5 H
PH 5 F
PH 5 H
PH 5 F
5
6
