AudioCodes Media 800 MSBR User Manual

User's Manual 938 Document #: LTRT-12809
Mediant 800 MSBR
66.11.9.3 Metering Tone Parameters
The metering tone parameters are described in the table below.
Metering Tone Parameters
Parameter Description
Web: Generate
Metering Tones
EMS: Metering Mode
CLI: gen-mtr-tones
[PayPhoneMeteringMo
de]
Determines the method used to configure the metering tones that are
generated to the Tel side.
 [0] Disable = (Default) Metering tones aren't generated.
 [1] Internal Table = Metering tones are generated according to the
device's Charge Code table (using the ChargeCode parameter).
Notes:
 This parameter is applicable only to FXS interfaces and ISDN Euro
trunks for sending AOC Facility messages (see Advice of Charge
Services for Euro ISDN on page 394).
 If you select 'Internal Table', you must configure the Charge Codes
table, using the ChargeCode parameter (see Configuring Charge
Codes Table on page 399).
Web: Analog Metering
Type
EMS: Metering Type
CLI: metering-type
[MeteringType]
Determines the metering method for generating pulses (sinusoidal
metering burst frequency) by the FXS port.
 [0] 12 KHz = (Default) 12 kHz sinusoidal bursts.
 [1] 16 KHz = 16 kHz sinusoidal bursts.
 [2] = Polarity Reversal pulses.
Notes:
 For this parameter to take effect, a device reset is required.
 This parameter is applicable only to FXS interfaces.
Web: Analog TTX
Voltage Level
EMS: TTX Voltage
Level
[AnalogTTXVoltageLe
vel ]
Determines the metering signal/pulse voltage level (TTX).
 [0] 0V = 0 Vrms sinusoidal bursts.
 [1] 0.5V = (Default) 0.5 Vrms sinusoidal bursts.
 [2] 1V = 1 Vrms sinusoidal bursts
Notes:
 For this parameter to take effect, a device reset is required.
 This parameter is applicable only to FXS interfaces.
Charge Codes Table
Web: Charge Codes
Table
EMS: Charge Codes
CLI: configure voip > gw
analoggw ChargeCode
[ChargeCode]
This table parameter configures metering tones and their time intervals
that the device's FXS interface generates to the Tel side or the E1 trunk
(EuroISDN) sends in AOC Facility messages to the PSTN (i.e., PBX).
The format of this parameter is as follows:
[ChargeCode]
FORMAT ChargeCode_Index = ChargeCode_EndTime1,
ChargeCode_PulseInterval1, ChargeCode_PulsesOnAnswer1,
ChargeCode_EndTime2, ChargeCode_PulseInterval2,
ChargeCode_PulsesOnAnswer2, ChargeCode_EndTime3,
ChargeCode_PulseInterval3, ChargeCode_PulsesOnAnswer3,
ChargeCode_EndTime4, ChargeCode_PulseInterval4,
ChargeCode_PulsesOnAnswer4;
[\ChargeCode]
Where,
 EndTime = Period (1 - 4) end time.
