48
Controls Opening and closing
3. Position both locking pins of one side at the
openings provided for them.
4. Press the wind deflector into the openings,
arrows 3, overcoming the tension in the
springs, and push the free locking pin in the
same direction, arrow 4.
5. Position the free locking pins at the corre-
sponding openings and let the spring
tension lock the wind deflector in place,
arrow 5.
6. Fold up the top section of the wind deflec-
tor, arrow 6.
With the wind deflector installed: do not
recline the front-seat backrests too far if
the seat is to be slid all the way back, as this
would damage the wind deflector.<
Removing the wind deflector
Proceed in the reverse order as used for instal-
lation.
Folding
Slide the red release lever towards the middle of
the wind deflector and push the two halves
apart.
Online Edition for Part no. 01402911223 - © 06/13 BMW AG
