Opening and closing
46
3. Push the securing pin 3 out until it engages.
4. Unfold the rear mounts 4.
Installing
1. Insert the securing pin 1 of the wind deflec-
tor into the appropriate opening on the right
side of the vehicle.
2. Guide the rear mounts 2 into the recepta-
cles provided.
3. Push the securing pin 3 on the left side into
the appropriate opening until it snaps into
place.
4. Fold up the upper half 4 of the wind deflec-
tor.
With wind deflector fitted: do not incline
the front seat backrests too far backward
if the seat is to be moved back to the end posi-
tion. Otherwise, the wind deflector will be dam-
aged.<
Removing
The same as installing, but in reverse order.
Folding up
1. Push the handle of the securing pin on the
wind deflector on the left side of the vehicle
all the way back and release the locking
mechanism.
2. Fold in the upper and lower section.
Online Edition for Part no. 01 41 2 600 775 - © 08/08 BMW AG
