BMW F 650 CS User Manual

2
28
Maintenance and care
• Insert tip of screwdriver in
groove 7 and carefully pry off
wheel cover 1
• Using screwdriver, pry out
split pin 2
e Attention:
Take care to keep the adapter
square when removing the
wheel nut.
• Using adapter, remove wheel
nut 3
•Remove cup spring4, thrust
washer 5 and taper ring 6
from the rear axle
• Remove the rear wheel from
the centring spigot
Removing rear wheel
3
2
7
1
20K14bkg3.book Seite 28 Mittwoch, 19. Mai 2004 11:57 11

BMW F 650 CS Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Seat Height	780 mm (30.7 in)
Engine Type	4-stroke, single cylinder
Power	50 hp (37 kW) @ 6, 500 rpm
Fuel System	Fuel injection
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Capacity	15 liters (4.0 US gal)
