Maintenance and care
Removing the battery
• Remove screw 8 of flashing
turn indicator
• Disconnect the plug of the
flashing turn indicator
• Remove three screws 5, 6,
and 7
• Remove the left cover from
the motorcycle
L Note:
When removing and installing
the cover, note expansion nut 9
on screw 5.
9
5
7
8
6
