17
1 Fuel gauge 75
2 Turn signal indicators 20
3 Speedometer
4 Indicator and warning
lamps 18 to 21
5 Tachometer and engine oil temper-
ature gauge 74
6 Engine coolant temperature
gauge 75
7 Indicator and warning
lamps 18 to 21
8 Control button for
>
Clock 77
>
Unit of measure of outside tem-
perature display 78
9 Display for sequential M gearbox
SMG II 66
10 Indicator lamp for Dynamic Stability
Control (DSC) 81
11 Display for
>
Trip odometer/Odometer 74
>
Clock 77
>
Service interval 76
>
Computer 78
12 Check Control 76
13 Trip odometer, reset to zero 74
14 Indicator and warning
lamps 18 to 21
Instrument cluster
OverviewControlsMaintenanceRepairsDataIndex
handbook.book Page 17 Saturday, July 27, 2002 1:12 PM
