Press and hold the two outer buttons on the in‐
terior mirror simultaneously for approximately
10 seconds until the LED on the interior mirror
flashes green rapidly.
Sun visor
Glare shield
Fold the sun visor down or up.
Glare shield from the side
Folding out
1.
Fold the sun visor down.
2. Unhook it from the holder and swing it to the
side.
3. Move it back to the desired position.
Folding up
Proceed in the reverse order to close the sun vi‐
sor.
Vanity mirror
A vanity mirror is located in the sun visor behind
a cover. When the cover is opened, the mirror
lighting switches on.
Ashtray
Front center console
Opening
1. Press onto the cover.
2. The ashtray is located in a cup holder. Fold
the ashtray cover upward.
Emptying
Pull the ashtray with the closed cover out of the
cup holder.
Seite 288
CONTROLS
Interior equipment
288
Online Edition for Part no. 01405A1E4B0 - X/20
