A) The working range increases depending on how well the laser light is reflected
from the surface of the target (scattered, not reflective) and with increased
brightness of the laser point to the ambient light intensity (interior spaces, twilight).
In unfavorable conditions (e.g. when measuring outdoors at intense sunlight), it may
be necessary to use the target plate.
B) For measurements from the rear measuring-tool edge. In unfavorable conditions
(e.g. at intense sunlight or an insufficiently reflecting surface), the maximum
deviation is ±10 mm per 80 m (±7/16 in per 265 ft). In favorable conditions, a
deviation influence of ±0.05 mm/m (±1/64 in per 26 ft) must be taken into account.
C) For measurements with the rear side of the unit as reference, the max. measuring
range is ±60°.
D) After calibration at 0° and 90° with an additional maximum pitch error of +/- 0,01°/°
until 45°.
E) In the continuous measurement function, the maximum operating temperature
is 104°F (+40°C).
F) at 77°F (25°C)
G) IP54 rating has not been evaluated by UL (Underwriters Laboratories Inc.). IP54
rating has been tested by Intertek.
H) For a new and charged battery without display illumination and tone signal.
Please observe the article number on the type plate of your battery charger. The
trade names of the individual battery chargers may vary.
Please observe the article number on the type plate of your measuring tool. The
trade names of the individual measuring tools may vary.
The measuring tool can be clearly identified with the serial number 18
on the type plate.
)
. ( )
1
( )
. ( )
5 ) 5 o )
. ( )
. ( ) .4” ( )
1
( )
. ( )
2 ( )
2
2
.3” x 24” x 1.2”
2 609 120 422 2 609 120 422
(
Output voltage 5.0 V= 5.0 V=
Charging current
Protection class
500 mA 500 mA
H) H)
G
-17-
