Operation
6.5.12.1 Adjusting the sag for the SR SUNTOUR air suspension fork
Only applies to pedelecs with this equipment
1 Turn the air valve cap (see Section 3.4.5.1)
anti-clockwise away from the air valve (fork).
2 Attach high-pressure damper pump to the air
valve (fork).
3 Pump air suspension to the required pressure
level. Stop at the levels specified in the SR
SUNTOUR pressure table for air suspension
forks. Never exceed the recommended
maximum filling pressure.
Recommended air pressure [psi]
Body weight
[kg]
RUX38/Durolux38
Durolux36/Auron35/
Mobie35
Axon34-werx/elite
Aion35/Zeron 45
Mobie34-air/
Mobie45 air
Axon34/
Raidon 34/
XCR34
Axon32/Epixon32/
Raidon32/XCR32-air
< 55 < 40 35… 50 40… 55 35… 50 40… 55 40… 55
55… 65 40… 50 50… 60 55… 65 50… 60 55… 65 55… 65
65… 75 50… 60 60… 70 65… 75 60… 70 65… 75 65… 75
75… 85 60… 70 70… 85 75… 85 70… 85 75… 85 75… 85
85… 95 70… 85 85… 105 85… 100 85… 105 85… 100 85… 100
>95 +85 +105 +100 +105 +100 +100
Filling pressure
set in the factory
70 90 95 90 95 110
Maximum
pressure
105 120 145 120 145 145
Suspension
operative up to
body weight [kg]
118 128 138 109 138 138
Table 59: SR SUNTOUR filling pressure table for air suspension forks
