11.3 Parts list
11.3.1 Premio EVO 10 Lite
23-15-2124, 23-15-2125, 23-15-2126
Gent, Trapez, Hydro Wave
Frame Cross Rider EVO 1 Aluminium, welded, frame shape and size:
Gent: 45 | 50 | 55 | 60 cm
Trapez: 45 | 50 | 55 cm
Wave: 45 | 50 | 55 cm
Rear frame damper … …
Tyres
Front | Rear
SCHWALBE, G-One Allround Gravel tyres
TLE, DD, RaceGuard
EPI: 67
Profile: HS473
Folding tyres
Weight: 760 g
Size: 57-622 (29")
Max. load: 120 kg
Printing: 1.8… 3.7 bar (26… 54 psi)
Max. load: 120 | 115 kg
Tube SCHWALBE, SV19B Light 40 mm Presta valve, valve length: 40 mm
Wheel … …
Rim Bulls, DDM-2 Aluminium, 700C, 13G × 36H
Spoke
Front | Rear
… Corrosion-resistant, 14G × 36H | 13G × 36H
Spoke nipples
Front | Rear
… Brass, 14G × 36H | 13G × 36H
Front wheel hub SHIMANO, ALIVIO HB-M4050QR Front wheel hub, with centre lock, aluminium
With SHIMANO quick release (QR), 36H
Rear wheel hub SHIMANO, ALIVIO FH-M4050 Aluminium, freewheel hub, with SHIMANO QR
quick release, centre lock, 36H
Steering headset FSA, NO, 57SC Aluminium, Aheadset, tapered: 1.5",
for fork steerer: 1-1/8", 8.4 mm
Stem KALLOY, AS-ZG4 Aluminium, Ahead stem, adjustable,
Handlebars clamp diameter: Ø 31.8 mm
Stem angle: +7°
Stem length (depends on frame size):
Gent: 45: 70 mm
Gent: 50: 90 mm
Gent: 55 | 60: 110 mm
Wave: 45 | 50: 70 mm
Wave: 55: 90 mm
Handlebars KALLOY, HBHR101 Aluminium,
Ø: 31.8 mm
Height: 25 mm
Backsweep: 5°/9°
Vertical angle: 5°
Length:
Gent: 700 mm
Wave: 680 mm
Handles | Tapers
Left hand | Right hand
ERGON, GP1 Bio-leather, winged grip
