3.5.12 Torque
Model Torque Tool
Axle
Conventional axle nut 35 … 40 Nm* 15 mm spanner
SR SUNTOUR screw-on axle
12AH2
Axle
Securing screw
8–10 Nm
5–6 Nm
6 mm hex bit
5 mm hex bit
SR SUNTOUR screw-on axle
15AH2
Axle
Securing screw
8–10 Nm
5–6 Nm
6 mm hex bit
5 mm hex bit
Indend Edge
Axle
Securing screw
3 … 5 Nm
10 Nm M6
Rechargeable battery
BOSCH PowerPack 400/500/600/
800
4 × attachment screws for casing
base locking mechanism
2 × attachment screws for cover
2 × attachment screws for cover
2 × attachment screws for bracket
on cable side
1 × attachment screw for bracket on
cable side
2 × attachment screws for bracket
on lock side
1 × attachment screws for bracket
on lock side
5 Nm
2 Nm
2 Nm
1.3 Nm
5 Nm
5 Nm
1 Nm
Torx® T25, M5 × 20
M3.5 × 12
M3.5 × 12 (pointed)
Torx® T15
Torx® T25, M5 × 20
Torx® T25
Torx® T15, M3.5 × 12
Display
FIT Comfort/Compact bracket
Attachment screw
0.5 Nm #
FIT Comfort/Compact
Mounting bracket 0.8 Nm #
On-board computer
FIT Remote Basic
Mounting bracket
0.8 Nm #
FIT Remote Display
Mounting bracket
0.8 Nm #
BOSCH Intuvia 100 bracket
Attachment screw 1,
M3 × 22
Attachment screw 2, M3× 14
1 Nm
1 Nm
3 mm hex bit
3 mm hex bit
BOSCH System Controller
Attachment screw 0.5 Nm Torx® T10
BOSCH Mini Remote
Attachment screw
0.4 Nm
(not 0.6 Nm, as written on mini-remote) 3 mm hex bit
SHIMANO SC-E5003
Attachment screw
0.8 Nm 3 mm hex bit
