7 Brushnozzle
8 Holder for crevice nozzle/brush nozzle
9 Crevice nozzle
10 Floor nozzle
11 Battery unlocking button
12 Filter assembly
13 Filter cover
14 Filter seal
15 Filter
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Assembly
Battery Charging
Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium-ion battery pack used in your vacuum cleaner.
Note: The battery supplied is partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
After the automatic shut-off of the vacuum cleaner, do
not continue to press the On/Off button. The battery
pack could become damaged.
Observe the notes for disposal.
Removing the battery (see figures A1 – A2)
The battery 3 is equipped with two locking levels that should
prevent the battery from falling out when pushing the battery
unlocking button 11 unintentionally. As long as the battery is
inserted in the power tool, it is held in position by means of a
spring.
– To remove the battery pack 3, press the battery unlocking
button 11 and pull the battery pack toward the rear out of
the vacuum cleaner. Do not exert any force when doing
this.
Mounting VAC Accessories (see figure B)
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments, changing accessories or storing the vacuum
cleaner. This safety measure prevents the vacuum cleaner
from being started accidentally.
The vacuum cleaner accessories can be connected directly to
the dust cup 5.
The combination possibilities of the various vacuum cleaner
accessories can be viewed in the figure.
– Connect the vacuum cleaner accessories firmly to the con-
nection at the dust cup 5 and in to each other.
Operation
Remove the battery before cleaning or performing
maintenance on the vacuum cleaner, making tool ad-
justments, changing accessories or storing the vacuum
cleaner. This safety measure prevents the vacuum cleaner
from being started accidentally.
Starting Operation
Do not use the vacuum cleaner in damp environments.
The penetration of rain or moisture into the top of the vac-
uum cleaner increases the risk of an electric shock.
Before vacuuming, ensure that the filter assembly is
assembled securely.
Only use an undamaged filter (no cracks, small holes,
etc.). Replace a damaged filter immediately.
Switching On and Off
To save energy, only switch the vacuum cleaner on when us-
ing it.
–To switch on the vaccum cleaner, move the On/Off switch
2 forwards (direction ON).
–To switch off the vaccum cleaner, move the On/Off switch
2 backwards (direction OFF).
Cordless dry vacuum cleaner PAS 18 LI
Article number
3 603 CB9 0..
Container volume (gross)
l0.65
Vacuum, max.
kPa 4.2
Airflow, max.
m
3
/min 1.4
Weight according to
EPTA-Procedure 01/2003 kg 1.3
Battery
Permitted ambient temperature
– during charging
– during operation
*
and during
storage
°C
°C
0...+45
–20...+50
Recommended batteries
PBA 18V ....V-.
PBA 18V ....W-.
Recommended chargers
– PBA 18V ....V-.
– PBA 18V ....W-.
AL 22.. CV
AL 18.. CV
AL 18.. CV
* Limited performance at temperatures <0 °C
Technical data determined with battery from delivery scope.
