14 | English
2 609 007 296 | (13.6.13) Bosch Power Tools
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 85 dB(A); Sound power level 96 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Cutting board: a
h
=13m/s
2
, K=3 m/s
2
,
Cutting sheet metal: a
h
=7m/s
2
, K=1.5 m/s
2
.
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signif-
icantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC.
Technical file (2006/42/EC) at:
Robert Bosch GmbH, PT/ETM9,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 29.05.2013
Assembly
 Before any work on the machine itself, pull the mains
plug.
Replacing/Inserting the Saw Blade
 When mounting the saw blade, wear protective gloves.
Danger of injury when touching the saw blade.
Selecting a Saw Blade
An overview of recommended saw blades can be found at the
end of these instructions. Use only T-shank saw blades or saw
blades with 1/4" universal shank (U-shank). The saw blade
should not be longer than required for the intended cut.
Use a thin saw blade for narrow curve cuts.
Inserting the Saw Blade (see figure A1)
 Clean the shank of the saw blade before inserting it. An
unclean shank cannot be fastened securely.
If required, remove the dust cover 9 (see “Dust Cover”).
Push the saw blade holder 13 upward in the direction of the
arrow. Insert the saw blade 15 (teeth in cutting direction) to
the stop into the saw blade holder.
While inserting the saw blade, pay attention that the back of
the saw blade is positioned in the groove of the guide
roller 14.
 Check the tight seating of the saw blade. A loose saw
blade can fall out and lead to injuries.
Removing the Saw Blade (see figure A2)
Push the saw blade holder 13 upward in the direction of the
arrow and remove the saw blade 15.
If the saw blade is wedged or jammed when removing, set ad-
justing lever 7 to maximum orbital action and press the saw
blade holder 13 lightly toward the front (max. 2 mm).
Saw Blade Storage (see figure B)
(PST 800 PEL/PST 8000 PEL)
Up to six saw blades with lengths to 110 mm can be stored in
the saw blade storage 5. Insert the saw blades with the T-shank
into the recess of the saw blade storage intended for this. Up to
three saw blades can be placed on top of each other.
Shut the saw blade storage and slide it to the stop into the
opening of the base plate 6.
Jigsaw PST 750 PE PST 800. PEL
Article number
3 603 CA0 5.. 3 603 CA0 1..
“Cut Control”
– 
Stroke rate control
 
Orbital action
 
Rated power input
W530 530
Output power
W290 290
Stroke rate at no load n
0
min
-1
500 –3000 500 –3000
Stroke
mm 20 20
Cutting capacity, max.
– in wood
–in aluminium
– in non-alloy steel
mm
mm
mm
75
12
5
80
12
5
Bevel cuts (left/right),
max.
°45 45
Weight according to
EPTA-Procedure
01/2003
kg 1.9 1.9
Protection class
/II /II
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
