OPERATING INSTRUCTIONS
SvenskaItalianoFrançaisEspañolDeutschDanskEnglish Nederlands
Using the tuner
An independent tuner is available on each input channel. The display indicates the
note being played at the bottom of the screen. As you tune, a pitch indicator
appears on the display, showing you whether the note is sharp or flat. Adjust the
pitch of your instrument so the cursor aligns itself with the center of the screen.
Note: For silent tuning, press the Mute button for the applicable channel.
Using global functions
The Global functions allow access to settings that affect the overall operation of the audio engine and all of its
channels. The Global functions are Scenes, Prefs, and Reverb Type.
Selecting a type of reverb
The Reverb Type function allows you to select the type of reverb that is applied to all
input channels. The decay time (Time) and balance (Bal) are adjustable. Balance
controls the ratio of early-to-late reflections.
1. Select Reverb Type with the T1 rotary selector.
2. Press the Typ e button to display the list of reverbs:
Plate............. Creates the ambience of a typical studio plate reverb. Features
adjustable time and balance (ratio of early/later reflections)
parameters. Works well with guitars, horns, percussion
instruments, and vocals.
Small............ Creates the ambience of a small-sized space. Features adjustable time and balance (ratio of
early/later reflections) parameters. Works well with guitars, horns, percussion instruments, and
vocals.
Medium........ Creates the ambience of a medium-sized space. Features adjustable time and balance (ratio of
early/later reflections) parameters. Works well with guitars, horns, percussion instruments, and
vocals.
CH 1 Tuner
A3
#
b
Pitch
indicator
All Channels Reverb Type
Type Time Bal.
Medium 1.20s 50%
To Next Page
