Page 7
Pre-Installation Notes
Passenger's Seat (Vans):
Position (shift) the passenger
seat fully forward prior to
installation procedures. In
vehicles equipped with custom
seats, it may be necessary to
remove the passenger seat prior
to installation and reinstall and/or
relocate upon completion. If the
seat is removed, keep all mount-
ing hardware for possible rein-
stallation.
Running Boards: If the vehicle
is equipped with running boards,
it may be necessary to remove
or modify the running boards to
provide adequate lift clearance.
Platform Drift:
Read this information before
removing the clear plastic
shipping wrap and/or placing
the lift in the vehicle.
Due to the “all-hydraulic” opera-
tion of the dual-cylinder L915
Series, hydraulic fluid expansion,
contraction or seepage may
occur. Any of these conditions
can result in platform drift (failure
to hold the platform in the folded
or raised position). Platform drift
may occur during lift shipment
and/or between extended periods
of non-lift use.
Plastic straps secure the lift in the
stowed position during shipment.
Before removing the shipping
straps, install the lift and power
the platform to the fully folded
position (press IN switch).
Chassis Ground:
The lift must be properly
grounded for proper operation.
Use of star washers, the external
ground cable and following the
outlined Chassis Ground Notice
procedures will provide optimum
ground.
External Tooth Star Washers:
In an effort to provide maximum
ground to the lift system, eight 3/8"
external tooth star washers are
now supplied with each lift.
Position star washers as detailed
in Installation Instructions.
External Ground Cable:
L915 pump modules feature an
external ground cable. Route the
external ground cable through the
floor grommet (details on page 17
of this manual). Secure the
ground cable below the floor with
one of the base plate mounting
bolts.
Chassis Ground Notice
(Mounting Bolt Ground):
When installing through-floor
mounting bolts, remove (grind,
sand, etc.) powder coating
(paint) from the area around one
or more lift base plate mounting
holes and remove any under-
coating, dirt, rust, etc. from the
underside of the vehicle floor
metal surface equal in size to the
mounting hardware in order to
provide optimum ground to the
electrical system. Apply a
protective coating of grease to
the mounting hole(s) and
underside of the vehicle where
bare metal is exposed to prevent
corrosion. Failure to follow
this procedure will void
warranty of certain electrical
components.
Lift Installation Checklist
A generic Lift Installation
Checklist is provided as a final
installation checklist to be given
to your customer. This checklist
is the last page in this manual.
Complete, remove (tear out) and
forward the Lift Installation
Checklist (or a copy) to your
customer to confirm that this lift
has been properly installed.
Preventive Maintenance
Checklist
A generic Daily Preventive
Maintenance Checklist is
provided in this manual (next
to last page) for your transit
agency’s use. The form can
be tailored to your particular
application.
W
A
RNING
Install lift and power
platform to fully
folded position before
removing shipping
straps. Failure to do
so may result in
serious bodily injury
and/or property
damage.
To Next Page
