Brother BX3000 User Manual

18
——————
—————————————————————————————————————————————————————————————————————————
—
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
1
e
While holding the thread from the spool
with your right hand, pass the thread
toward you, in the groove on the thread
guide.
• Make sure that the spring in the groove
catches the thread.
1 Spring
f
Feed the upper thread as shown in the
following illustration.
g
Make sure you guide the thread through
the thread take-up lever from right to left
as shown in the following illustration.
1 Thread take-up lever
Memo
● If the thread take-up lever is lowered, the
upper thread can not be wrapped around
the thread take-up lever. Make sure you
raise the needle by turning the handwheel
toward you (counterclockwise) so that the
mark on the wheel points up.
h
Put the thread behind the guide above the
needle.
• The thread can easily be passed behind the
needle bar thread guide by holding the
thread in your left hand, then feeding the
thread with your right hand.
1 Needle bar thread guide
i
Thread the needle from front to back
leaving a thread tail of about 5 cm
(2 inches).
• If your sewing machine is equipped with a
needle threader, use the needle threader to
thread the needle (see next section).
1 5 cm (2 inches)
Note
● Make sure you raise the presser foot lever
and the thread take-up lever before you feed
the upper thread.
● If you incorrectly feed the thread you may
cause sewing problems.
1
1
2
3
4
5
1
1
1
1

Brother BX3000 Specifications

General

Sewing machine accessories included	Zigzag foot
Power supply type	-
Display	No
Free arm	Yes
Sewing speed	750
Stitch width	5 mm
Product color	Violet, White
Stitch length	4 mm
Number of programs	20
Sewing machine functions	Sewing
Number of stitch patterns	2
Number of needle positions	3

Weight and Dimensions

Depth	392 mm
Width	148 mm
Height	308 mm
Weight	4700 g
