CHAPTER 2 "PCL" - 66
*Segment Size (UI) - indicates the size of each item in the data segment.
*Data segment -
AP - Application support segment (reserved)
CC - Character Complement
Function and form are as same as character complement flag in the font descriptor. This is only for
unbound fonts.
CP - Copyright
Value should be ASCII data.
GI - Global Intellifont data (reserved)
GT - Global TrueType Data
This segment consists of a table directory and several tables for the TrueType font scaler.
The table directory consists of a 12-byte header and 16 bytes pen entry.
IF - Intellifont Face Data (Reserved)
PA - PANOSE Descriptor
This data segment is used for font selection and substitution.
PF - PS-compatible font name (Reserved)
XW - X-Windows font name
5.4.4. Sending a character code
Esc*c#E (character code) (27)(42)(99)#(69)
<1Bh><2Ah><63h>#<45h>
•
This command sends a character code for the bitmap font ( MSL number for unbound fonts ) to the printer.
The font data must follow immediately.
• # is the character code. # can be from 0 to 65535. The specified character is defined by the data which
follows the character code.
• Use this command also to designate a character for deletion from a font, using the command for deleting a
character from a downloaded font.
5.4.5. Sending a character descriptor and data
Esc(s#W (character descriptor and character data)
(27)(40)(115)#(87) <1Bh><28h><73h>#<57h>
•
This command sends a character descriptor block and raster data describing the shape of the character to the
printer.
• # is the total number of bytes (descriptor and data) which will follow this command and can be up to 32767.
If you need to send more than 32767 bytes to describe a single character you must split it into blocks of
32767 bytes or less and send each block separately.
• The character header for the first block of data describing a character is in the following format.
[Bitmap font ]
Byte Data
0 - 1 Format Continuation
2 - 3 Descriptor size Class
4 - 5 Orientation Reserved
6 - 7 Left offset
8 - 9 Top offset
10 - 11 Character width
12 - 13 Character height
14 - 15 Delta X
16 - Raster Character Data
