Table 4 - Electrical data (heat pump)
38YL 09 12 18 24 28 36 48 60
+ ++ ++++++
40JX 009 012 018 024 028 036 048 060
Operation voltage V/Ph/Hz ❍❍❍❍❍/●❍/●●●/●●●/●
CONSUMPTION
Nominal (on cooling) * kW 1,00 1.22 1.79 2.20 2.77 3.48 4.0 5.15
Amp 4,52 5.52 8.10 10.10 12.53/4.77 15.75/5.24 13.5/7.95 18.4/10.6
Nominal (on heating) ** kW 0,92 1.10 1.67 2.20 2.61 2.74 3.80 4.65
Amp 4,16 4.97 7.56 10.10 11.80/3.93 12.40/4.13 13.7/7.9 17.2/9.90
Máximum (on coolig) *** kW 1,20 1.46 2.15 2.69 3.32 4.17 4.43 6.58
Amp 5,43 6.60 9.73 12.17 15.02/5.0 18.87/6.28 14.8/8.53 23.6/13.58
Máximum (on heating) **** kW 1,10 1.32 2.00 2.04 3.13 3.29 5.11 6.0
Amp 4,98 5.97 9.05 9.23 14.16/4.71 14.89/4.95 17.1/9.84 21.5/12.38
On short circuit Amp 28,5 35.0 51.5 78.0 84.5/47.5 108.0/49.0 103.0/53.0 124.0/64.0
NOTAS:
* Outdoor dry bulb temp. = 35
o
C; Indoor wet bulb temp. = 19
o
C.
** Outdoor wet bulb temp. = 6
o
C; Indoor dry bulb temp. = 21
o
C.
*** Outdoor dry bulb temp. = 46
o
C; Indoor wet bulb temp. = 21
o
C.
**** Outdoor wet bulb temp. = 18
o
C; Indoor dry bulb temp. = 24
o
C.
Tabella 4 - Dati elettrici (Pompa di calore)
38YL 09 12 18 24 28 36 48 60
+ ++ ++++++
40JX 009 012 018 024 028 036 048 060
Tensione nominale V/Ph/Hz ❍❍❍❍❍ / ●❍ / ●●● / ●●● / ●
ASSORBIMENTO
Nominale (raffrescamento) * kW 1,00 1,22 1,79 2,20 2,77 3,48 4,0 5,15
Amp 4,52 5,52 8,10 10,10 12,53/4,77 15,75/5,24 13,5/7,95 18,4/10,6
Nominale (riscaldamento) ** kW 0,92 1,10 1,67 2,20 2,61 2,74 3,80 4,65
Amp 4,16 4,97 7,56 10,10 11,80/3,93 12,40/4,13 13,7/7,9 17,2/9,90
Massimo (raffrescamento) *** kW 1,20 1,46 2,15 2,69 3,32 4,17 4,43 6,58
Amp 5,43 6,60 9,73 12,17 15,02/5,0 18,87/6,28 14,8/8,53 23,6/13,58
Massimo (riscaldamento) **** kW 1,10 1,32 2,00 2,04 3,13 3,29 5,11 6,0
Amp 4,98 5,97 9,05 9,23 14,16/4,71 14,89/4,95 17,1/9,84 21,5/12,38
Corrente di spunto Amp 28,5 35,0 51,5 78,0 84,5/47,5 108,0/49,0 103,0/53,0 124,0/64,0
NOTAS:
* Temperatura esterna b.s. = 35
o
C; Temperatura interna b.u = 19
o
C.
** Temperatura esterna b.u. = 6
o
C; Temperatura interna b.s. = 21
o
C.
*** Temperatura esterna b.s. = 46
o
C; Temperatura interna b.u. = 21
o
C.
**** Temperatura esterna b.u. = 18
o
C; Temperatura interna b.s. = 24
o
C.
38YL + 40JX
Heat pump
Pompa di calore
Pompe à chaleur
Wärmepumpe
Bomba de calor
❍ Outdoor unit operation voltage 230V ~ 50Hz
● Outdoor unit operation voltage 400V 3N~ 50Hz
●● Outdoor unit operation voltage 230V 3N~ 50Hz
❍ Unità esterna con tensione nominale 230V ~ 50Hz
● Unità esterna con tensione nominale 400V 3N~ 50Hz
●● Unità esterna con tensione nominale 230V 3N~ 50Hz
