Carrier 40JX 024 User Manual

8
Table 2 - Electrical data (cooling only)
38GL 0912182428364860
+ ++ ++++++
40JX 009 012 018 024 028 036 048 060
Operation voltage V/Ph/Hz ❍❍❍❍❍/●❍/●●●/●●●/●
CONSUMPTION
Nominal * kW 1.03 1.23 1.82 2.26 2.80 3.53 4.05 5.20
Amp 4.56 5.45 8.23 10.20 12.67/4.22 16.0/5.32 13.6/7.80 18.6/10.7
Máximum ** kW 1.23 1.47 2.18 2.71 3.36 4.23 4.50 6.60
Amp 5.56 6.65 9.86 12.30 15.20/5.06 19.15/6.37 15.07/8.67 23.6/13.6
On short circuit Amp 28.5 35.0 51.5 78.0 84.5/47.5 108.0/49.0 103.0/53.0 124.0/64.0
NOTES:
* Outdoor dry bulb temperature = 35
o
C; Indoor wet bulb temperature = 19
o
C.
** Outdoor dry bulb temperature = 46
o
C; Indoor wet bulb temperature = 21
o
C.
❍ Outdoor unit operation voltage 230V ~ 50Hz
● Outdoor unit operation voltage 400V 3N~ 50Hz
●● Outdoor unit operation voltage 230V 3N~ 50Hz
Tabella 2 - Dati elettrici (solo raffrescamento)
38GL 0912182428364860
+ ++ ++++++
40JX 009 012 018 024 028 036 048 060
Tensione nominale V/Ph/Hz ❍❍❍❍❍ / ●❍ / ●●● / ●●● / ●
ASSORBIMENTO
Nominale * kW 1,03 1,23 1,82 2,26 2,80 3,53 4,05 5,20
Amp 4,56 5,45 8,23 10,20 12,67/4,22 16,0/5,32 13,6/7,80 18,6/10,7
Massimo** kW 1,23 1,47 2,18 2,71 3,36 4,23 4,50 6,60
Amp 5,56 6,65 9,86 12,30 15,20/5,06 19,15/6,37 15,07/8,67 23,6/13,6
Corrente di spunto Amp 28,5 35,0 51,5 78,0 84,5/47,5 108,0/49,0 103,0/53,0 124,0/64,0
* Temperatura esterna b.s. = 35
o
C; Temperatura interna b.u. = 19
o
C.
** Temperatura esterna b.s. = 46
o
C; Temperatura interna b.u. = 21
o
C.
❍ Unità esterna con tensione nominale 230V ~ 50Hz
● Unità esterna con tensione nominale 400V 3N~ 50Hz
●● Unità esterna con tensione nominale 230V 3N~ 50Hz
NOTE:
38GL + 40JX
Cooling only
Solo raffrescamento
Refroidissement seul
Nur Kühlung
Sólo frío
