TOP VIEW
FRONT VIEW RIGHT SIDE VIEW
LEFT SIDE VIEW
UNIT
30HK
DIMENSIONS — in. (mm)
ABCD
040
5
1
⁄ 4
(133)
90
(2286)
14
9
⁄ 16
(370)
7
15
⁄ 16
(202)
050,060
10
3
⁄ 4
(273)
108
(2743)
20
1
⁄ 16
(510)
13
9
⁄ 16
(344)
LEGEND
COMP — Compressor
K.O. — Knockout
MTG — Mounting
SAE — Society of Automotive Engineers (U.S.A.)
NOTES:
1. Standard unit shown with the sound enclosure
accessory.
2. Dimensions are in inches unless otherwise
indicated.
Dimensions in ( ) are in millimeters.
3. Service clearance for the control box is 36-in.
Fig. 4 — 30HK040-060 (Fluid Cooled)
