HDB - Carrier Room Controller 2
GB - 1
ENGLISH
Read this manual carefully before using the appliance.
Contents Page
General information ......................................................................................... 2
Use ................................................................................................................. 2
Operation ..................................................................................................... 2/3
Owner’s manual
Display of selected functions
Room Controller 2
*NOTE: Because of the inherent characteristics of the display, the fan speed icon is displayed at the same time than the louver one though the
louvers are not controlled by the unit.
The fi xed position of each single wing cannot be displayed in the louver icon, which can instead be set in the corresponding confi guration
menu.
Off
Desired temperature / room temperature
Set-point setting indicator
Louver position
Fan speed
Bar-graph (appears at power-up only)
Automatic mode
Operating mode (Cooling and Heating)
Dry mode
A = Display
C = Key for selecting the
operating mode
D = Key for increasing
temperature/changing
louver setting
E = Button for selecting
the fan speed/
selection of louver
mode
F = Key for decreasing
temperature/changing
louver setting
S = Room temperature
sensor
V = Back panel fi xing
screws
A D
E S
F
V
C
V
