Casio AL-100R Service Manual

— 11 —
CODE NO. PARTS NAME SPECIFICATION Applicable Q
Price
Code
R REMARKS
Main PCB
1
1005 2374
PCB ASSY/M437-MA1M M241560*1 TK(M437) Common 1 EI A
D1
7911 4127
DIODE RB520S-30TE61 Common 1 AA B
D2
1004 7442
DIODE/ZENER HZU2.7B2TRF Common 1 AA B
IC1
1004 7445
IC/MONOLITHIC NJM2068MD(T1) Common 1 AC B
IC10
2105 3696
IC/C-MOS TC7SH04FU-TE85L Common 1 AB B
IC11
2105 6394
IC/C-MOS TC7SET08FU-TE85L Common 1 AB B
IC13
2105 5824
IC/C-MOS TC7SH32FU-TE85L Common 1 AB B
IC14
2105 3773
IC/MOS TC7SH08FU-TE85L Common 1 AB B
IC16
2105 5712
IC TC7S04FU(TE85L) Common 1 AB B
IC17
1004 7449
IC/MOS RN5VD28AA-TR Common 1 AC B
IC18
2105 3773
IC/MOS TC7SH08FU-TE85L Common 1 AB B
IC19
1001 4779
IC TC7W32FK(TE85L) Common 1 AD B
IC2
1000 8350
LSI PCM69BU/2K Common 1 BA A
IC3
1000 8349
LSI PCM1800E/2K Common 1 BH A
IC4
1002 1416
IC/MOS RN5RF35BA-TR Common 1 AE B
IC5.IC12
2105 6389
IC/C-MOS TC7SET04FU-TE85L Common 2 AD B
IC6,IC15
2105 3696
IC/C-MOS TC7SH04FU-TE85L Common 2 AB B
IC7
2112 0616
IC/MOS TC7WU04F(TE12L) Common 1 AC B
IC8,IC9
2105 6576
IC/C-MOS TC74LCX245FT(EL) Common 2 AF B
LSI1
2012 5987
LSI TC190C020AF-001 Common 1 BC A
LSI10
1004 7429
LSI ML6757GA-115 Common 1 BN A
LSI2
1005 4502
LSI UPD914AGM-3ED Common 1 CK A
LSI3
1004 3417
LSI CY62126BVLL-55ZIT Common 1 BR A
LSI4
1004 7441
LSI D2364000ALGY524JE3 Common 1 BZ A
LSI5
1004 7440
LSI D2364000ALGY523JE3 Common 1 BZ A
LSI6
1004 7434
LSI UPD70F3107GJ-M437A Common 1 DF A
LSI7
1000 8354
LSI HM62W16258BLTT-5 Common 1 CL A
LSI8
1006 3354
LSI MR27V3202E-J9MA-N Common 1 BN A
LSI9
1006 3353
LSI MR27V3202E-J8MA-N Common 1 BN A
Q1
2251 0672
TRANSISTOR 2SB1548-P.CS Common 1 AD B
Q2
2250 1162
TRANSISTOR 2SA1576A-T106R Common 1 AA B
Q3
2252 1169
TRANSISTOR 2SC4081-T106S Common 1 AA B
Q4,Q6
2252 1169
TRANSISTOR 2SC4081-T106S Common 2 AA B
Q5
2250 1162
TRANSISTOR 2SA1576A-T106R Common 1 AA B
X1
1004 7439
OSCILLATOR CSTCV16.00MXJ0C4-T Common 1 AC B
X2
1002 1357
OSCILLATOR DSX151GA-22.5792M Common 1 AS B
X3
1004 7437
OSCILLATOR CSTCC8.00MG16953-T Common 1 AD B
X4
1004 7438
OSCILLATOR CSTCR5M00G35-R0 Common 1 AC B
Power supply PCB
2
1005 2372
PCB ASSY/M437-PS2M M241556*1 TK(M437) Common 1 DJ A 120V area
2
1006 3968
PCB ASSY/M437-PS2M M241556*2 TK(M437) Common 1 DN A 230V area
BT400
3815 0658
BATTERY/LITHIUM CR2354-1HF Common 1 AN B
D200
1004 7556
ZENER DIODE MTZJT-7720A Common 1 AA B
D201-D208, D410,
D412,D413,D419,
D420,D422,D424
2315 3132
DIODE 1SS133T-77 Common 15 AA B
D401,D402,
D404-D409
1004 7403
DIODE 1N5401-EP Common 8 AA B
D411
1004 7558
ZENER DIODE MTZJT-779.1C Common 1 AA B
D415
2390 0371
DIODE DSK10B-BT-T Common 1 AA B
D416
1000 8352
DIODE FMB-G14L Common 1 AF B
D421,D423,D425
1004 7557
ZENER DIODE MTZJT-778.2B Common 3 AA B
Notes: Q -
Quantity per unit
R -
Rank
ITEM NO.
