FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
Main PCB
BT301 3815 0714 Lithium battery CR1220/1VC 1 130 B
N D301 2390 2555 Chip schottky diode RB500V-40TE-17 1 24 B
IC302 2105 5173 MOS IC RN5VD42AA-TR 1 75 B
LSI301 2012 2072 LSI UPD912GF-3BA(T) 1 750 A
LSI302 2012 2079 LSI HG51B227FB-1
1 500 A
LSI303 2012 1890 LSI MX23C8100MC-12CA27
1 600 A
N LSI304 2012 1764 LSI LC3564SM-85-TRM 1 320 A
LSI305 2012 0777 LSI LC33832M-70-TLM 1 410 A
LSI306 2105 4746 LSI UPD6379GR-E1 1 150 A
Q301 2250 1162 Chip transistor 2SA1576A-T106R 1 8 B
Q302 2252 0637 Chip transistor 2SC4081-T106R 1 6 B
N
X301 2590 2387 Crystal oscillator HC-49/US24B 1 110 B
N X302 2590 2079 Ceramic oscillator CSACS16.00MX040-TC 1 68 B
N 1 6924 4790 Main PCB ass'y M358-MA1M M240318*1 1 5,590 A
Console PCB
LED401 - 406 2370 0630 LED LN282RPX-(TX3)
621B
SW401 - 411
3412 0903 Tact switch EVQ-21405R
11 14 A
VR401 2765 0280
Slide volume
EWA-NAXCH1B14 1 100 A
N 2 6924 4860 Console PCB ass'y M358-CN1M M240321*1 1 1,220 A
Amp. PCB
D101 2390 2366 Diode stack S4VB20-4033(L10) 1 190 B
N F102
3632 0427 Fuse, time-lag (S)T-6.3A
162A
F102 3632 0420 Fuse, time-lag UL-TSC-6.3A-N1 1 62 A
IC101 2114 1883 IC, Amp. LA4620 1 270 A
IC102, IC104 2114 1799 IC, OP-amp. M5218APR 2 35 B
IC103 2114 1421 IC, photocoupler PC900V 1 100 B
J101/102 3612 0789 Jack YKB21-5010 2 35 A
J103 3501 4816 DIN jack YKF51-5051 1 100 B
Q101 2253 0455 Transistor 2SD1762E,F 1 47 A
Q102 - 106, 2220 1387 Transistor 2SC1740SQ-TP-T
88A
Q109 - 111
Q107/108 2253 0420 Transistor 2SD1468SR,S-TP-T 2 16 A
ZD101 2360 2044 Zener diode MTZJ6.2AT-77-T 1 8 A
N ZD102 2360 2737 Zener diode MTZJ10CT-77-T 1 8 A
N ZD103 2360 2772 Zener diode MTZJ13CT-77-T 1 8 A
ZD104 - 106 2360 1946 Zener diode MTZJ5.6CT-77-T 3 8 A
N3
6924 8210 Amp. PCB ass'y M358-PS2M M140332*2
1 3,180 A
PS1 & PS3M PCBs
F101 3632 0287 Fuse, time-lag (S)T-0.63A 1 49 A
F101 3632 0294 Fuse, time-lag MT4-2A-N1 1 64 A
N 4 6924 4840 PCB ass'y M358-PS3M M340345*1 1 880 B
N 5 6924 4920 PCB ass'y M358-PS4M M340346*1 1 470 B
J104 3613 1533 Jack, phone HLJ4336-01-3040 1 170 A
Other electrical parts
LED101
2320 9748 LED LN28RPH
120B
6
3613 0217 Receptacle NC-174-10-C
1 110 C
N7
3012 1449
Transformer
TE-358-1M1
1 1,290 B
8
6924 5260 Power button M340318-1
113B
9 3412 1827 Power switch SDDLD1-A2-D 1 130 A
Keyboard unit
N 10 6924 1810 Keyboard unit 88TP/8CASIO 1 7,180 B
N 11 ~ 17 6924 9040 White key, 1-octave 88TP8(42123530) 7 450 A
N 20 6924 9030 Black key, 1-octave 88TP8(42123460) 7 360 A
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
— 21 —
