Casio CTK-4200 Service Manual

CTK-4200
– 2 –
Musical Information Function Tone, Rhythm, Song Bank numbers and names, staff notation,
ngering, pedal operation, tempo, measure and beat number,
chord name, etc.
Inputs/Outputs
USB port TYPE B
Sustain/Assignable jack Standard jack (sustain, sostenuto, soft, rhythm)
Phones/Output jack Stereo standard jack
Output Impedance: 140 Ω, Output Voltage: 4.5 V (RMS) MAX
Audio In jack Stereo mini jack
Input Impedance: 9 kΩ, Input Sensitivity: 200 mV
Power Jack 9.5 V DC
Power Supply 2-way
Batteries 6 AA-size zinc-carbon batteries or alkaline batteries
Battery Life Approximately 3 hours continuous operation on alkaline batteries
AC Adaptor AD-E95100L
Auto Power Off Approximately 6 minutes (during battery operation) or 30 minutes
(during AC adaptor operation) without any operation, Auto Power Off
can be disabled.
Speakers 12cm × 2 (Output: 2.5W + 2.5W)
Power Consumption 9.5 V 7.7 W
Dimensions 94.8 × 35.0 × 10.3 cm (37
5
/
16
× 13
3
/
4
× 4
1
/
16
inch)
Weight Approximately 4.3 kg (9.5 lbs) (without batteries)
* This data is stored in a shared memory area with a total capacity of approximately 320 Kbytes
(1 Kbyte = 1,024 bytes).

Casio CTK-4200 Specifications

General

MIDI-keyboard number of keys	- keys
Interface	USB
Dimensions (WxDxH)	648 x 350 x 102 mm
Product color	Black, Silver

Weight and Dimensions

Weight	4599 g
