Casio PX-410R Service Manual

— 22 —
PX400R PX575R
Main PCB
N 1 10249876 PCB ASSY/MAIN TK-RJM507274*001 1 1 A
L13 10158809 COIL DLP31SN221SL2L 1 1 X
IC7 10198126 MEMORY CY62128DV30LL70ZAX 1 1 C
D2 23902058 DIODE 1SR154-400TE25 1 1 X
D1 10199220 DIODE HZU4.3B2TRF-E 1 1 X
IC2 10197390 MEMORY LP62S2048AX70LLTFQ 1 1 C
IC3 10195928 IC UPD63200GS-E1-A 1 1 C
IC6 10197802 IC TC74VHCT08AFT(EL.K 1 1 C
IC19,20 10197808 IC TC7SZ08FU(TE85L.F) 2 2 X
IC11,13,
17,27
10179619 IC TC7SZ04FU(TE85L.F) 4 4 C
IC5 10197796 IC TA75S393F(TE85L.F) 1 1 C
IC10,12,
23,24
10197555 IC TC7SZ14FU(TE85L.F) 4 4 C
IC14 10197809 IC TC7WH123FU(TE12L.F 1 1 X
IC25 10240648 IC TC74LCX08FT(EL.K) 1 1 C
IC16 10197798 IC TC74LCX138FT(EL.K) 1 1 C
F7,8 10122975 NETWORK/R-C EZASSB516BJ 2 2 B
F1-6,
F9-14
10122976 NETWORK/R-C EZASTB63ABJ 12 12 B
Q1 10153685 FET 2SJ346(TE85L.F) 1 1 C
Q2,3 69300298 TRANSISTOR 2SC4081T106R 2 2 X
Q5,Q6 10015566 TRANSISTOR 2SB1181TLR 2 2 C
Q4 10197813 TRANSISTOR 2SD2150T100R 1 1 C
X2 10211946 RESONATOR SSM1200000F17F5FZ8 1 1 C
X1 10208977 RESONATOR SSM1638400F16FSFZ8 1 1 C
SD CARD PCB
N 2 10249881 PCB ASSY/SDA1 TK-RJM507283*001 1 1 C
Sub PCB PS1
N 3 10249877 PCB ASSY/PSA1 TK-RJM507275*001 1 1 B
D203,204 10209003 DIODE 1N5822-F100 1 1 X
IC202 10203081 IC LA4636-E 1 1 C
IC203 10171297 IC M65850P 1 1 C
IC201,
204,206
10206677 IC NJM2068D-D 3 3 C
IC205 10201503 IC PQ1CG21H2FZH 1 1 C
L201,202
,203
10206680 COIL R2318-RB53856397NP 3 3 X
L204 10208248 COIL R187-860400NP 1 1 X
D205 10085189 DIODE DZ5.6BSBTA 1 1 C
D201 10137846 DIODE DZ7.5BSBTA 1 1 C
D206 10132124 DIODE DZ8.2BSBTA 1 1 C
Q201 10025042 TRANSISTOR 2SD1468STPR 1 1 C
Q204 10206675 TRANSISTOR KTA1273-Y-AT/P 1 1 C
Q203,205,
208,209
10206673 TRANSISTOR KTC3199-GR-AT/P 4 4 C
Jack PCB
N 4 10249878 PCB ASSY/PSC1 TK-RJM507276*001 1 1 C
J401,J402 10206815 CONNECTOR JY-6314*01-030 2 2 C
L401,L402 10206680 COIL R2318-RB53856397NP 2 2 C
Notes: N- New parts R -A: Essential
Q- Quantity used per unit B: Stock recommended
R- Rank C: Others
X: No stock recommended
Price
Code
N Item
Parts
code
Parts Name RemarksSpecification
QTY
R
