4-72
Instrument Panel Jumper Wiring Harness
This harness is included with the heavy-duty trailer
wiring package. The harness is for an electric trailer
brake controller and includes a trailer battery feed fuse.
This harness and fuse should be installed by your dealer
or a qualified service center.
Four
-Wire Trailer Harness Adapter
If you need to tow a
light
-duty trailer with a
standard four
-way round
pin connector, an adapter
is included.
Connect the adapter with the tab (arrow) pointing
towards the top. The cap on the wiring harness will lock
onto the tab (arrow) and help hold the adapter in place.
