Catalyst 4948E and Catalyst 4948E-F Switch Installation Guide
OL-21561-02
Chapter 1 Product Overview
Figure 1-1 Catalyst 4948E and Catalyst 4948E-F Switches—Front View of Chassis
(Catalyst
4948E Switch Shown)
Note The orientation of the Cisco logo shown in Figure 1-1 identifies the chassis as a Catalyst 4948E switch.
The Cisco logo that appears on the Catalyst
4948E-F chassis top cover is rotated 180 degrees. Additional
labels are placed on the Catalyst
4948E-F top cover to denote the direction of the airflow through the
chassis.
1 48 downlink ports 4 Status LEDs
2 4 uplink ports 5 Console port
3 Management port
278083
5
3
4
1
2
