Cisco Aironet Series Power Injectors AIR-PWRINJ-60RGD1= and AIR-PWRINJ-60RGD2= Installation Instructions
Connectors on the Power Injector
Warning To prevent airflow restriction, allow clearance around the ventilation openings to be at least:
3 to 4 inches (7.6 to 10.1 centimeters) Statement 1076
Warning Installation of the equipment must comply with local and national electrical codes. Statement 1074
Caution The power injector AC power termination must be accessible at all times, as it serves as the main
disconnect device to the unit.
Warning To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. Statement 1023
Connectors on the Power Injector
Figure 1 Earth Ground Connector on the Head of the Power Injector
Figure 2 Power and Data Connectors on the Base of the Power Injector
