10
Getting Started
RE1000 Range Extender
How to use Site Survey
The Site Survey gives a snapshot of all neighboring access points or routers
within range of the extender.
To open the Site Survey page:
1.
Log into the browser-based utility (see “How to open the browser-based
utility” on page 6).
2.
Click the Wireless tab, then click the Site Survey page.
SSID—Displays the name of neighboring wireless networks.
Signal Strength—Displays the relative position of the neighboring
APs by indicating the power of the wireless signal received: 1 bar= 20%,
2 bars=40%, 3 bars=60%, 4 bars=80%, 5 bars=100%. If no bar is displayed,
the extender is located too far away from the upstream AP. Try to keep
the signal strength between 60% and 100% for optimum performance.
A careful site survey will help in keeping this value within acceptable
range to benefit from optimum performance.
Security—Displays the mode of security in use by the neighboring APs.
To associate your extender with your known access point or router:
1.
Make a note of the SSID and the security passphrase that your access
point or router is actually configured with. This information will be useful
to carry on setup after the site survey is done.
2.
Select the network name (SSID) that you want to repeat with your
extender by clicking the corresponding dot in the left column.
3.
Click Connect. You are prompted for the passphrase used to secure your
wireless network. The type of security information required in this screen
needs to match your access point or router’s wireless security settings.
4.
Enter the passphrase, then click Save Settings. Your extender wireless
parameters should be configured. The wireless interface restarts, and the
extender associates with the access point or router you have chosen.
