DescriptionModule
The MF10-6RU unit is referred to as the MPO fan-out
unit.
A combination of 10 double-slot
NCS2K-MF-10AD-CFS, NCS2K-MF-16AD-CFS,
NCS2K-MF-16AE-CFS, NCS2K-MF-MPO-16LC
(NCS2K-MF-M16LC-CV), NCS2K-MF-MPO-20LC,
and NCS2K-MF-8X10G-FO units can be installed in
this unit.
NCS2K-MF10-6RU= (MF10-6RU)
Blank unit for the MF-6RU unit.NCS2K-MF-1SL-CVR=
Blank unit for the MF-10-6RU unit.NCS2K-MF-2SL-CVR=
USB cable; two meters longNCS2K-USB3-CBL-2=
USB cable; three meters longNCS2K-USB3-CBL-3=
Plastic transparent cover for the MF-6RU and
MF-10-6RU unit.
NCS2K-MF-6RU-CVR=
All passive optical modules, (except the mesh patch panel module), are installed using the rack mounting
bracket that is one rack unit (RU) high and can be directly connected to the NCS 2015 ECU. The passive
optical modules can also be installed in the fiber shuffle or MPO fan-out unit.
The following table lists the passive optical modules:
DescriptionModule
16-channel colorless omni-directional add/dropNCS2K-MF-16AD-CFS=
4-channel colorless omni-directional add/dropNCS2K-MF-4X4-COFS=
MPO to 8-LC adapterNCS2K-MF-MPO-8LC=
5-degree mesh moduleNCS2K-MF-DEG-5=
4-degree upgrade moduleNCS2K-MF-UPG-4=
MPO-16 to 16-LC fan-out moduleNCS2K-MF-MPO-16LC=
Double MPO-16 to two MPO-8 adapter moduleNCS2K-MF-2MPO-ADP=
16-port add/drop module with express capabilityNCS2K-MF-16AE-CFS=
10-port add/drop moduleNCS2K-MF-10AD-CFS=
8-degree mesh patch panel with 5 add/drop portsNCS2K-PPMESH8-5AD=
5-degree mesh connection verification module with
MPO-8 loopback caps (NCS2K-MPO-LBK=)
NCS2K-MF-DEG-5-CV=
4-degree upgrade connection verification module with
MPO-8 loopback caps (NCS2K-MPO-LBK=)
NCS2K-MF-UPG-4-CV=
Installing the Cisco NCS 2000 Series Passive Optical Modules
2
Installing the Cisco NCS 2000 Series Passive Optical Modules
