This product requires short-circuit (overcurrent) protection, to be provided as part of the building installation.
Install only in accordance with national and local wiring regulations.
Caution
The Cisco NCS 560-4 Router installation must comply with all the applicable codes and is approved for use
with copper conductors only. The ground bond fastening hardware should be of compatible material and
preclude loosening, deterioration, and electrochemical corrosion of hardware and joined material. Attachment
of the chassis ground to a central office or other interior ground system must be made with a 6 AWG gauge
wire, copper ground conductor at a minimum.
Note
The maximum power draw of the Cisco NCS 560-4 Router chassis and its configurable hardware components
are listed in the following table. The maximum power draw values are not affected by whether the router
chassis contains 1 or 2 power supplies AC or DC.
Maximum Power Draw ValueHardware Component(s)
(approx.) 500WRouter chassis with 2 power supplies, 3 fan trays, and 1 RSP4
54 WN560-4-PWR-FAN
80 WN560-4-FAN-H
164 WN560-4-RSP4 and N560-4-RSP4E (active)
164 WN560-4-RSP4 and N560-4-RSP4E (standby)
164 WN560-4-RSP4-CC and N560-4-RSP4E-CC (active)
164 WN560-4-RSP4-CC and N560-4-RSP4E-CC (standby)
55 WA900-IMA8Z (8-port 10 Gigabit Ethernet Interface Module)
55 WA900-IMA8CS1Z-M (8/16-port 1 Gigabit Ethernet (SFP/SFP) + 1-port 10
Gigabit Ethernet (SFP+) / 2-port 1 Gigabit Ethernet (CSFP) Interface Module)
75 WA900-IMA2C (2-port 100 Gigabit Ethernet Interface Module)
55 WA900-IMA8Z-CC (8-port 10 Gigabit Ethernet Interface Module)
55 WA900-IMA8CS1Z-CC (8/16-port 1 Gigabit Ethernet (SFP/SFP) + 1-port 10
Gigabit Ethernet (SFP+) / 2-port 1 Gigabit Ethernet (CSFP) Interface Module)
75 WA900-IMA2C-CC (2-port 100 Gigabit Ethernet Interface Module)
Electrical Circuit Requirements
Each Cisco NCS 560-4 Router requires a dedicated electrical circuit. If you equip it with dual power feeds,
provide a separate circuit for each power supply to avoid compromising the power redundancy feature.
Cisco NCS 560-4 Router Hardware Installation Guide
26
Preparing for Installation
Electrical Circuit Requirements
