144
III
BOOT - HIGH CARGO NET - G RA ND C 4 P IC A SS O
Net for retaining high loads
This enables you to maximise the vehicle’s load-
space.
It retains objects, preventing them from sliding towards
the front of the passenger compartment.
You insert it under the roller of the luggage-cover
blind, securing it on the third-row side mouldings.
Position 1 (5-seat configuration, behind the
second row)
To install the roller :
1. Remove the protection covers located under the
blind roller notches.
2. Position the roller under that of the luggage-cover
blind.
3. Raise the flap on the blind, positioning it on top of
the blind.
4. Deploy the net, passing it between the rollers and
the seats.
5. Pull the net upwards.
6. Anchor it to the roof by means of the fixing points
(after you have removed their covers).
To remove :
- Perform these operations in reverse order.
Position 2 (2-seat configuration, behind the
first row)
To install the roller :
1. With the second-row seats folded away, remove
the covers of the Isofix anchoring points located
on the seat backrests.
2. Secure the roller on the Isofix anchoring points.
3. Deploy the net and pull it upwards.
4. Anchor it to the roof by means of the fixing points
(after you have removed their covers).
