Clevo N750BU User Manual

Disassembly
Removing the Wireless LAN Module 2 - 13
2.Disassembly
Removing the Wireless LAN Module
1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 7).
2. The Wireless LAN module will be visible at point on the mainboard (Figure 8a).
3. Carefully disconnect the cables & , and then remove the screw (Figure 8b)
4. The Wireless LAN module (Figure 8c) will pop-up, and you can remove it from the computer.
1
2
3
4
5
b.
c.
a.
2
3
5
1
5
4

5.Wireless LAN Module
•1 Screw
Figure 8
WLAN Module
Removal
a. Locate the WLAN.
b. Disconnect the cable
and remove the screw.
c. The WLAN module will
pop up and lift it out of
the computer.
Note: Make sure you
reconnect the antenna
cable to the “1 + 2”
socket (Figure 8b).
