Disassembly
Wireless LAN, Combo Module Cables 2 - 15
2.Disassembly
Wireless LAN, Combo Module Cables
Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, and LTE modules are not
labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identifi-
cation as outlined in the table below.
Cable 1 is usually connected to antenna 1 on the module, and cable 2 to antenna 2.
Module Type
Antenna
Type
Cable Color
Cable Cover
Type
WLAN/WLAN & Bluetooth
Combo
WL 1 Black Transparent
WL 2 Black White
To Next Page
