7
Operation
Speaker/Microphone/Charge Jack
•
Your microTALK
®
radio can be fitted with an external Speaker/Microphone,
freeing your hands for other tasks. This same jack also serves as the
connecting point for the wall charger/adapter.
To attach a speaker/microphone:
1. Open the speaker/microphone/charge
tab on top of your microTALK
®
radio.
2. Insert the plug into the speaker/
microphone/charge jack. (See page 5 for power
output settings while using speaker/
microphones.)
To connect a wall charger/adapter:
1. Open the speaker/microphone/charge
tab on top of your microTALK
®
radio.
2. Insert the wall charger/adapter plug
into the speaker/microphone/charge jack.
Earbud Microphone
•
1. Plug earbud microphone into radio.
2. Place earbud in ear.
3. Clip microphone onto clothing 3” to 6” from your
mouth.
4. Push to talk.
Signal Strength Meter
•
Your microTALK
®
radio has a Signal Strength
Meter that shows the strength of your incoming
and outgoing transmissions. The ascending bars
next to the signal strength indicate the strength of
the signal. The greater the number of bars visible,
the stronger the signal. The fewer number of bars
visible, the weaker the signal.
6
Using Your Radio
Auto Squelch/Maximum Range
•
Your microTALK
®
radio is equipped with Auto Squelch, which
automatically shuts off weak transmissions and unwanted noise
due to terrain and conditions. This slightly reduces the Maximum
Range at which signals can be heard.
You can turn off auto squelch to allow all signals to be
received and extend the maximum range of your radio.
To briefly turn off auto squelch:
– Press the Light/Max Range button
for less than five (5) seconds.
If you hear two (2) beeps, you have turned
the maximum range extender on (see below).
To turn maximum range extender on:
– Press and hold the Light/Max Range button for at
least five (5) seconds until you hear
two (2) beeps which indicates the maximum
range extender is on.
To turn maximum range extender off:
– Press and release the Light/Max Range
button or change channels.
Lock Feature
•
The Lock feature locks the Channel, Mode, Hi•Low and Power
buttons to prevent accidental operation.
To turn the lock feature on or off:
– Press and hold the Lock/Enter button for
two (2) seconds.
A double beep sound is used to confirm your lock
on or off request. When in Lock mode,
the Lock icon will be displayed.
Operation
Light/Max Range
Lock/Enter Button
Lock Mode
Speaker/Microphone/
Charge Jack
Signal Strength
Radio Charger Jack
1
Placed in Ear
2
Clipped to Clothing
3
Push to Talk
4
To Next Page
