11
INSTALLING THE SEAT SAFETY
SWITCH
1. Squeeze the side clips of the safety switch (A, Figure
2), and insert the switch into the slot (B) in the seat
bottom. Be sure to slide the switch fully forward.
2. Connect the harness terminal housing (C) to the seat
switch.
3. Loop the wire tie (D) around both the switch body and
the terminal housing.
C
A
B
B
C
D
A
A
C
Figure 2. Installing the Seat Safety Switch
Not for
Reproduction
