PART NO. DESCRIPTIONREF NO QTY.
Transmission Group
Footnotes
ZTS 6000 -107.289930
CARRIAGE BOLT, 5/16-18 x 1-1/4, G5 1 1960223SM 2
WASHER, .34 ID x 1 OD x .13 THK 2 1919381SM 4
SPACER 3 1703900SM 2
NUT, Hex Keps, 5/16-18 4 1960684SM 2
ROD, Control L.H. 5 1727555SM 1
ROD, Control R.H. 6 1727556SM 1
BOLT, Shoulder 7 1727831SM 2
NUT, Hex Flange Two-Way Lock, 7/16-14 8 1930650SM 6
CAPSCREW, Hex Head, 7/16-14 x 2-1/4, G8 9 1927120SM 4
CAPSCREW, Hex Head, 5/16-18 x 2-3/4, G5 10 1923141SM 4
WASHER, .34 ID x 3/4 OD x .06 THK 11 1919326SM 6
CLIP, Rod End Linkage 13 1717024SM 1
ROD, Tow Valve L.H. 14 1733913SM 1
CARRIAGE BOLT, 3/8-16 x 1-1/4, G5 15 1960268SM 1
CARRIAGE BOLT, 1/2-13 x 1-1/2, G5 16 1960758SM 1
DRAWBAR 17 1733305ASM 1
CAPSCREW, Hex Head, 5/16-18 x 2-1/2, G5 18 1921719SM 2
CLIP, Rod End Linkage 19 1725550SM 1
ROD, Tow Valve R.H. 20 1733914SM 1
NUT, Hex Flange Whiz Lock, 5/16-18 21 1931277SM 6
NUT, Wheel Hex, 1/2-20 22 5020601SM 8
SUPPORT, Transmission Center 23 1733309ASM 1
TRANSMISSION, Hydro Gear EZT L.H. 24 1733351SM 1
TRANSMISSION, Hydro Gear EZT R.H. 25 1733352SM 1
SUPPORT, Transmission Rear 26 1733302ASM 1
NUT, Hex Flange, 3/8-16 ESNA 27 1960687SM 3
NUT, Hex Flange, 1/2-13 28 5025396SM 1
BOLT, Shoulder 29 1728976SM 1
WASHER, .34 ID x .87 OD x .06 THK 30 1924874SM 1
NUT, Hex Flange, 5/16-18 31 1927557SM 1
CAPSCREW, 3/8-16 x 2-1/2 Hex Head, GR5 32 7091501SM 1
V-BELT, Transmission Drive, 54.4 33 1732224SM 1
NUT, Hex Flange Two-Way Lock, 3/8-16 34 1930645SM 3
WASHER, .41 ID x 1-1/2 OD x .12 THK 35 1924356SM 2
CAPSCREW, Hex Head, 3/8-16 x 1, G5 36 1921210SM 2
SPRING, Extension 37 1734316SM 1
SPACER, Powdered Metal 38 1729007SM 1
ARM, Idler 39 1733303ASM 1
PULLEY, Idler Flat 40 1721133SM 1
WASHER, .41 ID x .87 OD x .08 THK 41 1924940SM 5
CAPSCREW, Hex Head, 3/8-16 x 2, G5 43 1923701SM 1
NUT, Push Pal, 3/8 44 1931942SM 1
NUT, Push Pal, 1/2 45 1960759SM 1
PTS - 9
