If there is no link on a port, such as when there is no computer
connected to the port or the connected computer is powered off,
D-Link’s Green Technology will enter a "sleep mode", drastically
reducing power used for that port.
• Power saving by cable length: 0~20m, 21~100m.
D-Link’s Green Technology detects the length of connected
Ethernet cable and adjusts power usage accordingly without
affecting performance. This way, a port connected to a 20m
cable only uses as much power as it needs, instead of using full
power, which is only needed for 100m cables.
Front-Panel Components
On the front panel of the Switch you will see the following.
LED status indicators
16 Auto-Negotiating 10/100/1000Mbps ports on the DGS-1016A
24 Auto-Negotiating 10/100/1000Mbps ports on the DGS-1024A
DGS-1016A Front Panel
DGS-1024A Front Panel
LED Indicators
The LED indicators of the Switch include a Power status indicator and
Link/Act/Speed indicator for each port.
LED Indicators
11
