D-Link DIR-632 User Manual

DIR-632 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in 8-port Switch
User Manual
Configuring via Web-based Interface
Parameter Description
MAC
A MAC address assigned to the interface. This parameter is
mandatory if your ISP uses MAC address binding. In the field, enter
the MAC address registered by your ISP upon concluding the
agreement.
You can click the Clone MAC Address button ( ) to set the
MAC address of the network interface card (of the computer that is
being used to configure the router at the moment) as the MAC
address of the WAN interface.
Also you can set the address of a device connected to the router's
LAN at the moment. To do this, select the relevant value from the
drop-down list (the field will be filled in automatically).
Figure 80. The page for creating a new connection. The PPP section.
Page 100 of 197

D-Link DIR-632 Specifications

Device Interface

LAN ports	8 10/100 LAN Ports
WAN port	1 10/100 WAN Port
device management	Internet Explorer v7 or Later; Mozilla Firefox v3.0 or Later; or other Java-enabled Browsers

Weight and Dimensions

item dimensions	230mm x 150mm x 33mm
packaging dimensions	276.9mm x 66mm x 205.8mm
item weight	272.2 grams
