35D-Link DIR-810L User Manual
Section 3 - Conguration
Internet Setup
DS-Lite
My Internet
Connection is:
DS-Lite
Conguration:
Select DS-Lite from the drop-down menu.
Select the DS-Lite DHCPv6 Option to let the router allocate
the AFTR IPv6 address automatically. Select the Manual
Configuration option to enter the AFTR IPv6 address in
manually.
AFTR IPv6
Address:
After selecting the Manual Configuration option above,
enter the AFTR IPv6 address used here.
B4 IPv4 Address: Enter the B4 IPv4 address value used here. (Optional.)
WAN IPv6
Address:
Once connected, the WAN IPv6 address will be displayed here.
IPv6 WAN
Default Gateway
Once connected, the IPv6 WAN Default Gateway address will
be displayed here.
DS-Lite is an IPv6 connection type. After selecting DS-Lite, the following parameters will be available for conguration:
