D-Link DSR-150 User Manual

D-Link DSR-Series User Manual 126
Section 7 - VPN
L2TP Active Users
A list of L2TP connections will be displayed on this page. Right-click the connection to connect and disconnect.
Note: The combined range of tunnels for PPTP and L2TP servers are given below:
Feature Limits
DSR-1000 Series DSR-500 Series DSR-250 Series DSR-150 Series
PPTP Tunnels 25 15 10 5
L2TP Tunnels 25 15 10 5
Combined Limit 50 30 20 10
The elds displayed in the table are given below.
Field Description
User Name
It displays the User name of the user(s) currently connected. Note that ‘*’ symbol indicates that the user
has connected without authentication.
Remote IP It displays the IP address that has been assigned to this particular user by the L2TP server.
L2TP IP It displays the local IP of the server.

D-Link DSR-150 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
PC in (D-Sub)	No
USB ports quantity	0
Ethernet LAN (RJ-45) ports	8
Supported network protocols	IPSec, PPTP, L2TP
Security algorithms	3DES, DES, SSL/TLS
VPN tunnels quantity	21
Filtering description	Keyword
MAC address filtering	-
Safety	cUL, LVD (EN60950-1)
Certification	WEEE
Electromagnetic compatibility	FCC Class B, CE Class B, C-Tick, IC
Mean time between failures (MTBF)	240000 h
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	7.44 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black
Input voltage	12 V
Ports quantity	The number of ports or external interfaces to which other equipment can be connected.
Management platform	HTTP, HTTPS, CLI, SNMP v1/v2c/v3
Connectivity technology	Wired
Compliance industry standards	RoHS

Weight and Dimensions

Depth	118 mm
Width	208 mm
Height	35 mm
Weight	- g
