D-Link DWA-110 User Manual

31D-Link DWA-110 User Manual
Section 4 - Security
Configure WPA/WPA2 Passphrase
Using the D-Link Utility
It is recommended to enable WPA-PSK on your wireless router or access point before configuring your wireless adapter. If you are
joining an existing network, you will need to know the WPA-PSK passphrase being used.
1. Open the Wireless Utility by double-clicking on the D-Link icon in your
system tray (lower-right corner of screen).
2. Highlight the wireless network (SSID) you would like to connect to
and click Connect. If the network is using WPA-PSK, the screen (as
shown to the left) will appear.
3. Enter the WPA-PSK passphrase exactly as it is on your wireless router
or access point. Click the Show text in the password field box to see
the passphrase. Unchecking it will hide it.
4. Click OK to connect to the network. Allow up to 30 seconds to connect.
If you would like to create a new network and enter the WEP settings, refer to the next page.

D-Link DWA-110 Specifications

General

Wi-Fi	Yes
Modulation	DBPSK
Wi-Fi band	Single-band (2.4 GHz)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Maximum data transfer rate	54 Mbit/s
Connectivity technology	Wireless
Output voltage	5 V
RX power consumption	280 mA
Dimensions (WxDxH)	87 x 28 x 12 mm
Compliance industry standards	IEEE 802.11g/b
Compatible operating systems	Windows 98SE, ME, XP SP2, 2000 SP4, Vista
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, Wi-Fi, WPS
