Section 3 - Conguration
Press the WPS button on the adapter and holding for two seconds until the
utility screen comes up. Then, press the WPS button on the router/access point
to continue.
The adapter will try to establish connectivity to your access point or wireless
router.
When this screen appears, you have successfully established connectivity.
Click Finish to complete your setup.
WPS UI will save the wireless connection prole named “security.htm” on the
desktop

D-Link DWA-127 Specifications

Power

power consumption (Tx)	230 mA
power consumption (Rx)	140 mA
operating voltage	5 VDC +/- 5%

Operating Environment

operating temperature	32°F to 104°F (0°C to 40°C)
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4GHz to 2.483GHz

Weight and Dimensions

dimensions	210 x 15 x 14 mm
weight	12.8 g
