D-Link DWR-118 User Manual

17D-Link DWR-118 User Manual
Section 4 - Conguration
Failover
This connection can serve as a backup for your default connection.
The Failover type can be set to either Disable, Load Sharing or Failover. With
Load Sharing, the data usage is distributed evenly over the two dierent Internet
connections. With Failover, the secondary Internet connection will be in standby
mode, until the primary Internet connection fails.
If you selected Load Sharing or Failover, the Remote Host for Keep Alive box
will appear, and should be set to an external IP address that can be used to ensure
that the 3G/4G LTE connection will be kept from going oine due to inactivity. An
example would be Google’s public DNS servers (8.8.8.8 or 8.8.4.4) or your ISP’s
DNS servers.
The Primary WAN will display your current Internet conguration type.
The Secondary WAN can be set by clicking Add, and the available options will be
shown in the drop down box that appears. Select 4G LTE/3G to use your mobile
connection as a backup.
When you have nished conguring your failover settings, click Apply to save
your changes. To restore your settings to the most recent save, click Reset.

D-Link DWR-118 Specifications

General

VPN support	L2TP/PPTP/IPSEC
Ethernet LAN	Yes
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	433 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	4
USB version	2.0
Rack mounting	No
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
Product color	Black
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Certification	RoHS, CE
Antenna gain level (max)	5 dBi
Package depth	274 mm
Package width	208 mm
Package height	66 mm
Package weight	706 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1975 mm
Pallet gross weight (air)	418480 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	230 mm
Shipping (inner) case length	360 mm
Shipping (inner) case weight	4130 g
Shipping (inner) case net weight	3530 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	113.5 mm
Width	148.5 mm
Height	25 mm
Weight	194.3 g
