D-Link DWR-933 User Manual

14D-Link DWR-933 User Manual
Section 3 - Conguration
Quick Access
A quick access page will be displayed on the initial home page for the DWR-933. The headings below link through to windows where you can alter
settings in more detail.
This area displays your Internet provider, the type of
Internet service you are using, signal strength, and
your current data usage.
This area displays the length of connection time and
allows you to change between Always Connect and
Manual Connect.
The Wi-Fi section displays the number of devices
currently connected to the router via Wi-Fi.
This area displays the number of SMS messages in
your inbox and your draft massages.
This area displays whether power saving features
have been enabled, such as suspend mode.
Internet
Connection Mode
Wi-Fi
Short Messaging
Power Saving

D-Link DWR-933 Specifications

General

SIM card slot	Yes
3G/4G USB modem compatibility	No
Product type	Portable router
Product color	Black
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN interface type	Not available
4G standard	LTE
3G standards	DC-HSDPA, HSPA, HSPA+, WCDMA
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS
Number of products included	1 pc(s)
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	64 GB
Ethernet LAN (RJ-45) ports	0
Output current	1 A
Output voltage	5 V
Battery capacity	2800 mAh
Power source type	Battery
Battery life (max)	16 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	BSMI, RoHS
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	64 mm
Width	105 mm
Height	14 mm
Weight	140 g
