D-Link EasySmart Switch User Manual
Figure 49 – VLAN > 802.1Q VLAN > Add VID
Figure 50 – VLAN > 802.1Q VLAN > Assign PVID
Rename: Click to rename the VLAN group.
Delete VID: Click to delete the VLAN group.
Figure 51 – VLAN > 802.1Q VLAN > VLAN Table
NOTE: When 802.1Q VLAN is enabled, the Port-
28

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link EasySmart DGS-1100-24 and is the answer not in the manual?

D-Link EasySmart DGS-1100-24 Specifications

General IconGeneral
Switching Capacity48 Gbps
Forwarding Rate35.7 Mpps
MAC Address Table Size8K
Jumbo Frame9, 216 bytes
Switch TypeManaged
Packet Buffer Memory512 KB
Humidity10% to 90% non-condensing
Ports24 x 10/100/1000BASE-T
QoS802.1p Priority Queues
Power SupplyInternal power supply
Operating Temperature0 to 40 °C
Storage Temperature-10 to 70 °C
