1-10
SERVICE INFORMATION
ITEM SPECIFICATIONS
1,965 mm
690 mm
1,230 mm
1,350 mm
780 mm
120 mm
125 kg
255 kg
Underbone
Telescopic / 77mm
Swing arm / 66mm
120 / 70 - 12 53k / Tubeless
130 / 70 - 12 62k / Tubeless
2.00 Kgf / ㎠ (200 kPa)
2.00 Kgf / ㎠ (200 kPa)
2.00 Kgf / ㎠ (200 kPa)
2.25 Kgf / ㎠ (225 kPa)
Hydraulic disk
Drum brake
8.0ℓ
1.7ℓ
25。
86 mm
90 ㎠
Oil cooled / air cooled 4 cycle SOHC engine
1(Single cylinder), front angle 80。
56
×50.7 mm
124.9 ㏄
10.8 : 1
SOHC chain drive
1.1ℓAfter disassembly
0.75ℓAfter Oil change
0.8ℓAfter Oil filter change
0.9ℓAfter Oil change with Oil in the Oil hose removed
Forced pressure splash type
Wet sump
14.0 kgf / ㎠ (550 rpm)
5。BTDC
14。ABDC
18。BBDC
1。BTDC
0.12±0.12 mm
0.12±0.12 mm
OVERALL LENGTH
OVERALL WIDTH
OVERALL HEIGHT
WHEEL BASE
SEAT HEIGHT
GROUND CLEARANCE
DRY WEIGHT
GROSS WEIGHT
TYPE
FRONT SUSPENSION / STROKE
REAR SUSPENSION / STROKE
FRONT TIRE SIZE / TYPE
REAR TIRE SIZE / TYPE
TIRE PRESSURE 1 PERSON FRONT
REAR
2 PERSON FRONT
REAR
FRONT / REAR BRAKE
PARKING BRAKE
FUEL TANK CAPACITY FULL CAPACITY
RESERVE CAPACITY
CASTER ANGLE
TRAIL
FRONT FORK OIL CAPACITY
TYPE
CYLINDERS / ARRANGEMENT
BORE AND STROKE
DISPLACEMENT
COMPRESSION RATIO
VALVE TRAIN
OIL CAPACITY
LUBRICATION SYSTEM
AIR CLEANER TYPE
CYLINDER COMPRESSION
INTAKE VALVE OPEN
CLOSED
EXHAUST VALVE CLOSED
CLOSED
VALVE CLEARANCE (COOLING-OFF PERIOD)
INTAKE
EXHAUST
DIMENSIONS
FRAME
ENGINE
SPECIFICATIONS
